Waterworks Easton Classic Pressure Balance Control Valve Trim with Oak Lever Handles - Manual (Page 2)

Easton ® Pressure Balance
11. WARNING: FAILURE TO ADJUST THE LIMIT STOP
SCREW PROPERLY MAY RESULT IN SERIOUS
SCALDING.
12. WARNING:THIS SHOWER SYSTEM MAY NOT
PROTECT THE USER FROM SCALDING WHEN THERE IS
A FAILURE OF OTHER TEMPERATURE CONTROLLING
DEVICES ELSEWHERE IN THE PLUMBING SYSTEM.
INSTALL THE TRIM:
13. Slide the trim plate assembly(9-10a) over the valve stem
and secure it against the wall using the screws(6) provided.
If desired, a bead of clear silicone can be applied to the back
side of the trim plate(10,10a).
14. Apply a small amount of lubricant to the o-ring(9) and then
hand tighten the dome cover(8) completely down onto the
spindle(TA-10).
15. Slide the handle trim spacer(7) onto the valve stem and
then attach the handle(5) using the screw provided(4).
16. Thread the index retainer(3) into the handle and then
attach the index(1) to the retainer using the adhesive
pad(2).
17. Open the valve and confirm the temperature setting, adjust
as required.To remove the index that is attached using the
adhesive pad, place your palm against the index and
unthread the index assembly(1-3).
➢ If further assistance is required, please contact Product
Support at 1-800-927-2120 (8am-7pm EST).
Installation Guidelines
W A T E R W O R K S ®
3/04
These guidelines have been prepared for the professional contractor to aid in the installation of:
EASTON ® PRESSURE BALANCE(EASV82-K,83-K,84-K,85-K-TRIM + GUSV80-
ROUGH)
All dimensions are based on original specifications and are subject to change and variation.
Please consult your Design Associate for current specifications.
gusv81R
9.14.07
