Julia Lavatory Faucet
These guidelines have been prepared for the professional contractor to aid in the installation of:
JULIA LAVATORY FAUCET WITH CROSS HANDLES (JULS18) & LEVER HANDLES
(JULS20-K, JULS21-K, JULS22-K) All dimensions are based on original specification and are subject to
change and variation. Please consult your Design Associate for current specifications.
JULS20-K
JULS21-K, 22-K
12d 2.2 GPM FLOW RESTRICTOR
