15. Tighten the lower tee nut (9a) to create a water

tight seal around the guide tube (11e).

IMPORTANT: if the tee nut is not tight, water will
leak out of the top of the guide tube or the tee

assembly.

16. Connect each of the supply hoses to the adjacent

side valve (7) making sure they are not
pinched/kinked.

17. Remove the upper collar (14c) from the pop-up

drain assembly and discard the upper gasket (14b).

18. Set the upper collar in the lavatory drain opening

using a clear adhesive silicone.

19. Re-attach the lower drain assembly (14) using the

gasket (14a) provided then tighten until fully secured.
A clear adhesive silicone may be used to ensure a
water-tight seal between the gasket and lavatory.

20.Remove the knurled nut (14f) from the lower drain

assembly then insert the horizontal pivot rod (14h)
and reattach the knurled nut.

21.Connect the vertical lift rod to the horizontal pivot

rod using the linkage (14g) provided. Note that these
rods may be field cut. An optional lift rod extension

(13c) is supplied.

22.Attach the tail piece (15,15b) using the gasket (15a)

provided. Hand tight is adequate.

23.Connect the side valves (7) to the water supply

valves (not supplied).

INSPECT THE INSTALLATION

24.Unscrew and remove the aerator assembly (12c-12f)

which includes a 2.2 GPM flow restrictor (12d)

25.Carefully open the hot and cold valves to flush out

any debris in the supply lines.

26.Inspect all connections for leaks.

27.Close the drain then fill the sink with water to make

sure the drain stopper (14e) operates and seals
properly. To adjust the height of the drain stopper

turn the adjustment screw at the base of the stopper
then tighten the locking nut to secure. The linkage

(14g) position will effect drain stopper function, adjust

as needed.

28.Close the valves and reinstall the aerator assembly.

If further assistance is required, please contact Product

Support at 1-800-927-2120 (8am-7pm EST)

Installation Guidelines

W A T E R W O R K S

Waterworks is a registered trademark of Waterworks Inc.

Julia Lavatory Faucet

These guidelines have been prepared for the professional contractor to aid in the installation of:

JULIA LAVATORY FAUCET WITH CROSS HANDLES (JULS18) & LEVER HANDLES

(JULS20-K, JULS21-K, JULS22-K) All dimensions are based on original specification and are subject to
change and variation. Please consult your Design Associate for current specifications.

10.06.06
