E
26
Use
and
to select the option you want:
• NARROW: 2mm (1/16") block spacing
• WIDE: 4mm (3/16") block spacing
• NONE: 0mm (0") block spacing
• NARROW: 6mm (
1
/
4
") margins
• NONE: 0mm (0") margins
• WIDE: 43mm (1
11
/
16
") margins
• MEDIUM: 20mm (
13
/
16
") margins
• See page 27 for more information.
• AUTO: Automatically adjusts tape length in
accordance with the number of characters.
• FIX: Maintains a fixed tape length in the range
of 0cm (0") to 99.9cm (39
5
/
16
"). See page 27
for more information.
• LEFT: Aligns blocks flush left.
• EQUAL: Equally spaces blocks to fill the entire
space available.
• CENTER: Centers blocks .
• RIGHT: Aligns blocks flush right.
• Note that this setting is available only when FIX
is selected for the T-LENGTH setting. See
page 29 for more information.
FREE DESIGN: Configuring Label Form Settings
Unlike the block form settings described in the previous section, label form
settings are applied to the entire tape label, even if the label consists of multi-
ple blocks.
■ To configure label form settings
1.
In the Free Design Mode, input the text you want.
2.
Press FORM.
• If your label has only one block, the block form settings (page 25) will
appear when you press FORM. If you perform the steps under “To
configure block form settings” on page 25, the label form settings in step
4 of this procedure will appear when you press SET (or
) to complete
the block form setting procedure (step 7 of “To configure block form
settings”).
3.
Use
and
to select ALL FORM, and then press SET.
4.
Use
and
to select the setting you want to change, and
and
to change the currently selected setting.
• You can also change the MARGINS setting when creating a label in the
Numbering Mode (page 17), and the MIRROR setting when creating a
label in the Numbering Mode (page 17) or the Enlarged Label Mode
(page 19).
5.
After all the label form settings are the way you want, press SET.
When this setting
is selected:
BL-SPACE
MARGINS
T-LENGTH
B-ALIGN
When this setting
is selected:
MIRROR
PROPOR-
TIONAL
SMOOTHING
Use
and
to select the option you want:
• NORMAL: Prints the tape normally.
• MIRROR: Prints the tape in mirror image onto
special optionally available iron transfer tape.
• ON: Automatically adjusts letter spacing to the
optional pitch.
• OFF: Spaces letters using a uniform pitch.
• ON: Smoothes printed lines to eliminate jagged
edges from text and graphics.
• OFF: No smoothing performed.
