Pilz PSEN op4B-S-3-080 User Manual
Page 31
Operating Manual
PSEN op4B Series
27
5.2 Aligning the muting sensors
•
Once the safety light curtain has been aligned and the muting
sensor profiles have been installed and wired, you will need to
check that the sensors on the profiles are aligned correctly. Slight
adjustments may be made by moving the fastening clip.
Fig. 21
