Getting Started 3–19
Using the PC
Using Multi-Channel Audio
Speakers
If your PC has the multi-channel audio speakers
option (select models only), you can connect four
channels (speakers) or six channels.
To use a multi-channel audio system with more than
two channels, you need to connect the speakers to
your PC and configure them for sound output.
Connecting a Multi-Channel Speaker
System to the PC
1. Turn off the PC.
2. Connect the three speaker plugs to the
connectors on the back of the PC.
Connect
speaker plugs To PC back
connector Connector
icon
Front speakers Audio Out
(lime-green)
Rear speakers Audio In (blue)
Center/subwoofer
speakers Mic-1 (pink)
OUT
IN
