87 www.kontron.com
User Guide
AM4024(E)
10.8 OEM Event/Reading Types
OEM (Kontron) specific sensor types and codes are presented in the following table.
Table 60: OEM Event/Reading Types
OEM SENSOR
TYPE (CODE) OEM EVENT/
READING TYPE (CODE)
DESCRIPTION
Firmware Info 1 (C0h) 70h Internal Diagnostic Data
Firmware Info 2 (C0h) 71h Internal Diagnostic Data
Board Reset (C4h) 6Fh
(sensor type specific) Sensor-specific Offset Event
00h Reserved
01h HwPowerReset
02h PCIReset
03h HwWatchDogReset
04h SoftReset
05h Reserved
06h ColdReset
07h IPMICommand
08h Reserved
09h Reserved
0Ah BMCWatchdog
IPMBL State (C3h) 6Fh
(sensor type specific) Sensor discrete State Meaning
04h IPMB-L running
others IPMB-L not running
Post Value (C6h) 6Fh
(sensor type specific) Sensor discrete State Meaning
Bits [7:0] Post Value (read from host I/O port
80h)
Bits [15:8] Reserved
Firmware Upgrade
Manager (C7h) 6Fh
(sensor type specific) Sensor-specific Offset Event
0h First Boot after upgrade
1h First Boot after rollback (error)
2h First Boot after errors (watchdog)
3h First Boot after manual rollback
4h Reserved
5h Reserved
6h Reserved
7h Reserved
8h Firmware Watchdog Bite, reset occurred
