User Guide
AM4024(E)
1.3 System Relevant Information
The following system relevant information is general in nature but should still be considered when de-
veloping applications using the AM4024(E).
1.4 Board Diagrams
The following diagrams provide additional information concerning board functionality and component
layout.
Table 1: System Relevant Information
SUBJECT INFORMATION
Hardware Requirements The AM4024(E) can be installed on any AMC-supporting carrier board or MicroTCA
backplane with the following AMC Card-edge connector port mapping:
AM4024:
» Common Options Region ports 0-1:
» Two Gigabit Ethernet SerDes ports
» Common Options Region ports 2-3:
» Two Serial ATA ports
» Fat Pipes Region ports 4-7:
» One x4 PCI Express interface
» Extended Options Region port 14-16:
» One Serial port
» One Debug port
» Two GPOs
» Clock:
» PCI Express reference clock, FCLKA
AM4024E:
» Common Options Region ports 0-1:
» Two Gigabit Ethernet SerDes ports
» Common Options Region ports 2-3:
» Two Serial ATA ports
» Fat Pipes Region ports 4-7:
» One x4 PCI Express interface
» Fat Pipes Region ports 8-11:
» Four Gigabit Ethernet SerDes ports
» Extended Options Region port 14-16:
» One Serial port
» One Debug port
» Two GPOs
» Clock:
» PCI Express reference clock, FCLKA
PCI Express Configuration The AM4024(E) supports the PCI Express root complex configuration.
Operating Systems The AM4024(E) is offered with various Board Support Packages including Windows,
VxWorks and Linux operating systems. For further information concerning the operat-
ing systems available for the AM4024(E), please contact Kontron.
