3.3.9 General Purpose Output Register (GPOUT)
The General Purpose Output Register holds the general purpose output signals of the AMC Card-edge
connector.
Table 33: General Purpose Output Register (GPOUT)
ADDRESS 0x292
BIT 7 6 5 4 3 2 1 0
NAME Reserved GPO1 GPO0
ACCESS R R/W R/W
RESET 0000 0 0 0
BITFIELD DESCRIPTION
1..0 GPO1..0 General purpose output signals:
0 = Output low
1 = Output high
