User Guide
AM4024(E)
10.4 Firmware Identif ication
10.4.1 Get Device ID Command
* Bytes 13 through 16 are optional and defined by Kontron.
Table 53: Get Device ID Command
COMMAND LUN NetFn CMD
Get Device ID 00h App = 06h 01h
REQUEST DATA
Byte Data Field
-- --
RESPONSE DATA
Byte Data Field
1 Completion code
2 10h Device ID
3 80h Device Revision
4 02h Firmware Revision 1: Major Firmware Revision
(varies depending on firmware revision)
5 00h Firmware Revision 2: Minor Firmware Revision, BCD encoded
(varies depending on firmware revision)
6 51h IPMI Version, holds IPMI command specification version, BCD encoded
7 B9h Additional Device Support
8..10 98h 3Ah 00h Manufacturer ID, LSB first
03A98h = 15000 = Kontron
11..12 10h B4h Product ID, LSB first
B410h = Identifies the board/family firmware
13* Release number of the IPMI firmware (varies depending on firmware revision):
10h for R10
11h for R11
14* Module geographical address (site number):
1 … 8 = Module in AMC bay A1, A2, A3, A4, B1, B2, B3, B4
or in μTCA slot 1 … 8 with bus addresses
72h, 74h, 76h, 78h, 7ah, 7ch, 7eh, 80h
9 …12 = Module in μTCA slot 9 … 12 = Bay C1, C2, C3, C4
with bus addresses 82h, 84h, 86h,88h
0, > 12 = Module position is not in range. The IPMB-L bus is
switched off
15..16* Reserved
