76 www.kontron.com
User Guide
AM4024(E)
The KCS interface serves for the communication between the AM4024(E)’s payload and the MMC. The
OS requires the KCS interface configuration during their loading time. The KCS interface configuration
is available in the “IPMI Device Information Record” included in the SMBIOS table.
10.3 Suppor ted IPMI and ATC A Commands
10.3.1 Standard IPMI Commands
The following table shows an excerpt from the command list specified in the IPMI specification 2.0. The
shaded table cells indicate commands not supported by the AM4024(E) IPMI firmware.
M = mandatory, O = optional
Table 51: Standard IPMI Commands
COMMAND IPMI 2.0 SPEC.
SECTION
NETFN CMD KONTRON SUPPORT
ON MMC
IPM DEVICE “GLOBAL” COMMANDS M
Get Device ID 20.1 App 01h M / Yes
Cold Reset 20.2 App 02h O / Yes
Warm Reset 20.3 App 03h O / No
Get Self Test Results 20.4 App 04h O / Yes
Manufacturing Test On 20.5 App 05h O / Yes
Set ACPI Power State 20.6 App 06h O / No
Get ACPI Power State 20.7 App 07h O / No
Get Device GUID 20.8 App 08h O / No
Broadcast “Get Device ID” 20.9 App 01h M / Yes
BMC WATCHDOG TIMER COMMANDS O
Reset Watchdog Timer 27.5 App 22h O / Yes
Set Watchdog Timer 27.6 App 24h O / Yes
Get Watchdog Timer 27.7 App 25h O / Yes
BMC DEVICE AND MESSAGING COMMANDS O
Set BMC Global Enables 22.1 App 2Eh O / Yes
Get BMC Global Enables 22.2 App 2Fh O / Yes
Clear Message Flags 22.3 App 30h O / Yes
Get Message Flags 22.4 App 31h O / Yes
Enable Message Channel Receive 22.5 App 32h O / Yes
Get Message 22.6 App 33h O / Yes
Send Message 22.7 App 34h O / Yes
Read Event Message Buffer 22.8 App 35h O / Yes
Get BT Interface Capabilities 22.9 App 36h O / No
Get System GUID 22.14 App 37h O / No
Get Channel Authentication Capabilities 22.13 App 38h O / Yes
Session Control 22.15 to 22.20 App 39h to 3Dh O / Yes
Get AuthCode 22.21 App 3Fh O / No
