10.6.1 Sensor List
The following table indicates all sensors available on the AM4024(E). For further information on Kon-
tron’s OEM specific sensor types and sensor event type codes presented in the following table, refer to
Chapter 10.8, OEM Event/Reading Types.
Table 57: Sensor List
SENSOR NUMBER /
ID STRING
SENSOR TYPE (CODE) /
EVENT/READING TYPE (CODE)
Assertion Mask /
Deassertion Mask/
Reading Mask
DESCRIPTION Health LED
Shows Error
00h /
A1:IPMI Info-1 OEM Firmware Info 1 (C0h) /
OEM (70h) 0003h / 0000h /
7FFFh For internal use only N
01h /
A1:IPMI Info-2 OEM Firmware Info 2 (C0h) /
OEM (71h) 0003h / 0000h /
7FFFh For internal use only N
02h /
A1:IPMI Watchdog Watchdog (23h) /
Sensor-specific (6Fh) 010Fh / 0000h /
010Fh Watchdog 2 Y
03h /
A1:FRU Agent OEM (C5h) /
Discrete (0Ah) 0140h / 0000h /
0147h FRU agent N
04h /
A1:Health Error Platform Alert (24h) /
Digital discrete (03h) 0000h / 0000h /
0003h Aggregate states (power, tem-
perature, etc.). Visualization
by the Health LED. Y
05h /
A1:MMC Reboot Platform Alert (24h) /
Digital discrete (03h) 0002h / 0000h /
0003h MMC reboot active state. Is
asserted during boot time. N
06h /
A1:Module-
HotSwap OEM (F2h) /
Sensor-specific (6Fh) 001Fh / 0000h /
001Fh Hot swap sensor N
07h /
A1:IPMBL State OEM (C3h) /
Sensor-specific (6Fh) 0007h / 0000h /
000Fh State of IPMB-L bus N
08h /
A1: MMC Stor Err Mgmt. Subsyst. Health (28h)
/ Sensor-specific (6Fh) 0002h / 0000h /
0003h Storage error N
09h /
A1: MMC FwUp Firmware Upgrade Manager
(C7h) / Sensor specific (6Fh) 010Fh / 0000h /
010Fh Status of Firmware Upgrade
Manager N
0Ah /
A1: Ver change Version Change (2Bh) / Sen-
sor specific (6Fh) 0002h / 0000h /
0002h MMC firmware upgrade detec-
tion N
0Ch /
A1:Board Reset OEM (C4h) /
Sensor-specific (6Fh) 04DEh / 0000h /
04DEh Board reset event Y
0Dh /
A1:Temp CPU Temperature (01h) /
Threshold (01h) 1A81h / 7A81h /
3939h CPU die temperature Y
0Eh /
A1:Temp PCH Temperature (01h) /
Threshold (01h) 0A80h / 7A80h /
3838h PCH temperature Y
0Fh /
A1:Temp Air Temperature (01h) /
Threshold (01h) 7A95h / 7A95h /
3F3Fh Air temperature near AMC
edge-connector Y
10h /
A1:Board 3.3vIPM Voltage (02h) /
Threshold (01h) 2204h / 2204h /
1212h AMC Management Power (MP)
3.3V Y
11h /
A1:Board 12.0v Voltage (02h) /
Threshold (01h) 2204h / 2204h /
1212h AMC Payload Power (PWR) 12V Y
