39 Rx3- SATA-B Receiver - Carrier 132 Tx15- COMA Serial Port Receive Carrier
40 GND Logic Ground - 131 GND Logic Ground -
41 ENABLE# AMC Enable Carrier 130 Rx15+ Not Connected Carrier
42 PWR Payload Power Carrier 129 Rx15- Not Connected Carrier
43 GND Logic Ground - 128 GND Logic Ground -
44 Tx4+ PCIe-0 Transmitter + AMC 127 Tx14+ Debug serial data output AMC
45 Tx4- PCIe-0 Transmitter - AMC 126 Tx14- Debug serial clock output AMC
46 GND Logic Ground - 125 GND Logic Ground -
47 Rx4+ PCIe-0 Receiver + Carrier 124 Rx14+ Not Connected Carrier
48 Rx4- PCIe-0 Receiver - Carrier 123 Rx14- Not Connected Carrier
49 GND Logic Ground - 122 GND Logic Ground -
50 Tx5+ PCIe-1 Transmitter + AMC 121 Tx13+ Not Connected AMC
51 Tx5- PCIe-1 Transmitter - AMC 120 Tx13- Not Connected AMC
52 GND Logic Ground - 119 GND Logic Ground -
53 Rx5+ PCIe-1 Receiver + Carrier 118 Rx13+ Not Connected Carrier
54 Rx5- PCIe-1 Receiver - Carrier 117 Rx13- Not Connected Carrier
55 GND Logic Ground - 116 GND Logic Ground -
56 SCL_L IPMB-L Clock IPMI
Agent
115 Tx12+ Not Connected AMC
57 PWR Payload Power Carrier 114 Tx12- Not Connected AMC
58 GND Logic Ground - 113 GND Logic Ground -
59 Tx6+ PCIe-2 Transmitter + AMC 112 Rx12+ Not Connected Carrier
60 Tx6- PCIe-2 Transmitter - AMC 111 Rx12- Not Connected Carrier
61 GND Logic Ground - 110 GND Logic Ground -
62 Rx6+ PCIe-2 Receiver + Carrier 109 Tx11+ GbE-11 Transmitter + AMC
63 Rx6- PCIe-2 Receiver - Carrier 108 Tx11- GbE-11 Transmitter - AMC
64 GND Logic Ground - 107 GND Logic Ground -
65 Tx7+ PCIe-3 Transmitter + AMC 106 Rx11+ GbE-11 Receiver + Carrier
66 Tx7- PCIe-3 Transmitter - AMC 105 Rx11- GbE-11 Receiver - Carrier
67 GND Logic Ground - 104 GND Logic Ground -
68 Rx7+ PCIe-3 Receiver + Carrier 103 Tx10+ GbE-10 Transmitter + AMC
69 Rx7- PCIe-3 Receiver - Carrier 102 Tx10- GbE-10 Transmitter - AMC
70 GND Logic Ground - 101 GND Logic Ground -
71 SDA_L IPMB-L Data IPMI
Agent
100 Rx10+ GbE-10 Receiver + Carrier
72 PWR Payload Power Carrier 99 Rx10- GbE-10 Receiver - Carrier
73 GND Logic Ground - 98 GND Logic Ground -
74 TCLKA+ Telecom Clock A+ Carrier 97 Tx9+ GbE-9 Transmitter + AMC
75 TCLKA- Telecom Clock A- Carrier 96 Tx9- GbE-9 Transmitter - AMC
76 GND Logic Ground - 95 GND Logic Ground -
77 TCLKB+ Not Connected AMC 94 Rx9+ GbE-9 Receiver + Carrier
Table 18: Pinout of AMC Card-edge Connector J1 on the AM4024E (Continued)
BASIC SIDE (COMPONENT SIDE 1) EXTENDED SIDE (COMPONENT SIDE 2)
PIN SIGNAL FUNCTION DRIVEN BY PIN SIGNAL FUNCTION DRIVEN BY
