52 www.kontron.com
User Guide
AM4024(E)
4.4 Payload Power Consumption of Accessor ies
The following table indicates the payload power consumption of AM4024(E) accessories.
4.5 IPMI FRU Payload Power Consumption
The following table indicates the IPMI FRU payload power consumption.
Table 36: Power Consumption of AM4024(E) Accessories
MODULE PAYLOAD POWER
SATA Flash module approx. 1.0 W
Gigabit Ethernet port connected on the front panel (per interface) approx. 0.5 W
Table 37: IPMI FRU Payload Power Consumption
AM4024(E) with Intel® Core™
i7-4860EQ (SV), 1.8 GHz
AM4024(E) with Intel® Core™
i7-4700EQ (SV), 2.4 GHz
AM4024(E) with Intel® Core™
i5-4402EQ (LV), 1.6 GHz
65 W 65 W 40 W
