9.2.2 Advanced Setup Menu
The Advanced Setup menu provides sub-screens and functions for advanced configuration.
Note: Setting items on this screen to incorrect values may cause the system to malfunction.
9.2.3 Security Setup Menu
The Security Setup menu provides information about the passwords and functions for specifying the
security settings. The passwords are case-sensitive. The AM4024(E) provides no factory-set passwords.
Note: If there is already a password installed, the system asks for this first. To clear a password,
simply enter nothing and acknowledge by pressing . To set a password, enter it
twice and acknowledge by pressing .
Table 45: Advanced Setup Menu Sub-Screens and Functions
SUB-SCREEN FUNCTION DESCRIPTION
Processor Configu-
ration CPU Flex Ratio Override Enables/Disables CPU Flex Ratio Programming.
CPU Flex Ratio Settings CPU Flex Ratio Settings: This value must be between Max. Efficiency
Ratio (LFM) and Maximum non-turbo ratio set by Hardware (HFM).
See Table 5, Features of the Processors Supported on the
AM4024(E), for possible LFM/HFM values. The active nominal CPU
frequency is Ratio*100MHz.
ME Configuration ME FW Downgrade Enables/Disables ME FW Downgrade function.
Table 46: Security Setup Menu Functions
FUNCTION DESCRIPTION
Supervisor Password is: Read-only field.
User Password is: Read-only field.
Set Supervisor Password Sets or clears the Supervisor Password .
Supervisor Hint String Press “Enter” to specify a hint string for the Supervisor Password.
Set User Password Sets or clears the User Password .
User Hint String Press “Enter” to specify a hint string for the User Password.
Min. password length Specifies the minimum password length.
Authenticate User on Boot Enables the user authentication prompt on the boot.
HDD Password Select Specifies whether to enable User-only support for HDD or User and Master support.
HDD00 Password State Read-only field.
Set HDD00 User Password Specifies and confirms the HDD User Password.
TPM Support Enables/Disables TPM support.
Table 47: TPM Configuration Sub-Screen
FUNCTION DESCRIPTION
Current TPM State Read-only field.
TPM Action Enacts TPM Action.
Note: Most TPM actions require TPM to be Enabled to take effect.
Omit Boot Measurements Enabling this option causes the system to omit recording boot device attempts in PCR[4].
