User Guide

AM4024(E)

Swi

DIP Switch

One DIP switch, SW2, for board configuration

Hot Swap

One Hot Swap switch

nnect

Front Panel Connectors

One Serial port (COMA) with RS-232 signal level on a 5-pin micro-AB USB connector, J11
One 20-pin mini DisplayPort connector, J5
Two Gigabit Ethernet ports on RJ-45 connectors with integrated magnetics, J3 and J4
One USB 2.0 port on a 5-pin, mini USB type A connector, J2

Onboard Connector

One extension connector, J7, for either a Serial ATA Flash module or an RTC Backup
Battery module

AMC Card-edge Connector One 170-pin AMC Card-edge connector

LEDs

Module Management LEDs

» LED1 (red):

Out-of-Service LED

» LED2 (red/green/amber):

Health LED

» HS LED (blue):

Hot swap LED

User-Specific LEDs

» ULED3 (red/green):

AMC port 0 Ethernet link status,
(green) + POST code

» ULED2 (red/green):

AMC port 1 Ethernet link status,
(green) + POST code

» ULED1 (red/green):

SATA channels active (green) + POST code

» ULED0 (red/green):

POST code

Ethernet LEDs

» Act (green):

Network Link / Activity

» Speed (green/yellow):

Network speed

Watchdog Timer

Software-configurable, two-stage Watchdog with programmable timeout ranging
from 125 ms to 4096 s in 16 steps
Serves for generating IRQ or hardware reset

System Timer

The Intel® QM87 Chipset contains three 8254-style counters which have fixed uses
In addition to the three 8254-style counters, the Intel® QM87 Chipset includes
eight individual high-precision event timers that may be used by the operating
system. They are implemented as a single counter each with its own comparator
and value register.

s. M

anag

ement

Thermal Management

CPU and board overtemperature protection is provided by:

» Temperature sensors integrated in the 4

gen. Intel® Core™ i7/i5 processor:

» Up to four digital thermal sensors for monitoring the processor cores, one

sensor for each core

» One digital thermal sensor for monitoring the graphics core
» One digital thermal sensor for monitoring the package die temperature

» One onboard air temperature sensor for monitoring the board temperature
» Specially designed heat sink

Table 2: AM4024(E) Main Specifications (Continued)

FEATURES

SPECIFICATIONS
