User Guide
AM4024(E)
12h /
A1:Board 5.0V
Voltage (02h) /
Threshold (01h)
2204h / 2204h /
1212h
Board 5V supply
Y
13h /
A1:Board 3.3V
Voltage (02h) /
Threshold (01h)
2204h / 2204h /
1212h
Board 3.3V supply
Y
14h /
A1:Pwr Good
Power supply (08h) /
OEM (77h)
0000h / 0000h /
0887h
States of all power lines
N
15h /
A1:Pwr Good Evt
Power supply (08h) /
OEM (77h)
0000h / 0887h /
0887h
Power fail events for all power
lines
Y
16h /
A1:CPU status
Processor (07h) /
Sensor-specific (6Fh)
0463h / 0400h /
04E3h
CPU aggregate status
Y
17h /
A1:FWH0 Boot Err
Boot Error (1Eh) /
Sensor-specific (6Fh)
0008h / 0008h /
0008h
Firmware Hub 0 boot error
Y
18h /
A1:FWH1 Boot Err
Boot Error (1Eh) /
Sensor-specific (6Fh)
0008h / 0008h /
0008h
Firmware Hub 1 boot error
Y
19h /
A1:POST Value
OEM Post Value (C6h) /
OEM (78h)
0000h / 0000h /
00FFh
POST Value (from host I/O port
80h)
N
1Ah /
A1:Link-GbE-A
LAN (27h) /
Sensor-specific (6Fh)
0000h / 0000h /
0003h
LAN link status –
Front port GbE-A (upper)
N
1Bh /
A1:Link-GbE-B
LAN (27h) /
Sensor-specific (6Fh)
0000h / 0000h /
0003h
LAN link status –
Front port GbE-B (lower)
N
1Ch /
A1:Link-AMC-0
LAN (27h) /
Sensor-specific (6Fh)
0000h / 0000h /
0003h
LAN link status –
AMC port 0
N
1Dh /
A1:Link-AMC-1
LAN (27h) /
Sensor-specific (6Fh)
0000h / 0000h /
0003h
LAN link status –
AMC port 1
N
1Eh /
A1:Link-AMC-8
(AM4024E)
LAN (27h) /
Sensor-specific (6Fh)
0000h / 0000h /
0003h
LAN link status –
AMC port 8
N
1Fh /
A1:Link-AMC-9
(AM4024E)
LAN (27h) /
Sensor-specific (6Fh)
0000h / 0000h /
0003h
LAN link status –
AMC port 9
N
20h /
A1:Link-AMC-10
(AM4024E)
LAN (27h) /
Sensor-specific (6Fh)
0000h / 0000h /
0003h
LAN link status –
AMC port 10
N
21h /
A1:Link-AMC-11
(AM4024E)
LAN (27h) /
Sensor-specific (6Fh)
0000h / 0000h /
0003h
LAN link status –
AMC port 11
N
Table 57: Sensor List (Continued)
SENSOR NUMBER /
ID STRING
SENSOR TYPE (CODE) /
EVENT/READING TYPE (CODE)
Assertion Mask /
Deassertion Mask/
Reading Mask
DESCRIPTION
Health LED
Shows Error
