User Guide
AM4024(E)
1.6 Standards
The AM4024(E) complies with the requirements of the following standards.
Note: Boards without conformal coating must not be exposed to a change of temperature which
can lead to condensation. Condensation may cause irreversible damage, especially when
the board is powered up again.
Kontron does not accept any responsibility for damage to products resulting from destruc-
tive environmental testing.
Please contact Kontron for assistance prior to performing further environmental testing of
the AM4024(E).
Table 3: Standards
TYPE ASPECT STANDARD TEST LEVEL
CE Emission EN55022, EN61000-6-3, EN300386 --
Immission EN55024, EN61000-6-2, EN300386 --
Electrical Safety EN60950-1 --
Mechanical Mechanical Dimensions IEEE 1101.10 --
Environmental and
Health Aspects Climatic Humidity IEC60068-2-78 93% RH at 40 °C,
non-condensing
(see note below)
WEEE Directive 2002/96/EC Waste electrical and electronic
equipment
RoHS 2 Directive 2011/65/EU Restriction of the use of certain
hazardous substances in electri-
cal and electronic equipment
Vibration
(sinusoidal, operating) GR-63-CORE
EN300019-2-3
IEC61131-2
IEC60068-2-6 5-150 [Hz] frequency range
1 [g] acceleration
1 [oct/min] sweep rate
10 sweeps/axis
3 directions: x, y, z
Shock (operating) EN300019-2-3
IEC61131-2
IEC60068-2-27 15 [g] acceleration
11 [ms] pulse duration
3 shocks per direction
5 [s] recovery time
6 directions, ±x, ±y, ±z
