KTD-S0002-I Page 60 Appendix B: Connector Layout
p ITX-SP User's Guide
Pin
microSD Socket
J3200
SDIO Pin Strip
J3201
Digital I/O
J3202
1 DAT2 VCC3 VCC3
2 CD / DAT3 N.C. GPIO4
3 CMD DAT0 GPIO0
4 VCC3 N.C. GPIO5
5 CLK DAT1 / IRQ GPIO1
6 GND GND GPIO6
7 DAT0 DAT2 / RW GPIO2
8 DAT1 /WP GPIO7
9 CD / DAT3 GPIO3
10 /CD GND
11 CMD
12 CLK
Pin
LAN
J2000
USB Standard
J3300
USB Extension
J3301 - J3304
1 TXD+ / BI_D1+ VCC5 GND
2 TXD- / BI_D1- USB0- USBn+
3 RXD+ / BI_D2+ USB0+ USBn-
4 BI_D3+ GND VCC5
5 BI_D3- VCC5
6 RXD- / BI_D2- USB1-
7 BI_D4+ USB1+
8 BI_D4- GND
Pin
S-ATA
J3401/02
HD Audio
J2900
S/PDIF
J2901
1 GND LINE_OUT_R GND
2 TX+ GND SPDIF_OUT
3 TX- LINE_OUT_L
4 GND LINE_IN_R
5 RX- MIC_IN
6 RX+ LINE_IN_L
7 GND
Pin
Power Header
J1804
Backlight
J1801
Battery
J1800
1 RST_BTN+ N.C. VBAT
2 PWR_BTN+ BKLTADJ GND
3 RST_BTN- GND
4 PWR_BTN- RSVD
5 HDD_LED- RSVD
6 RSVD GND
7 HDD_LED+ BKLTON
8 RSVD
9 RSVD
10 RSVD
