KTD-S0002-I Page 44 Setup Guide
p ITX-SP User's Guide
18.5.2.5 USB Configuration Submenu
Feature Option Description
Module Version N / A Show USB module version
USB Devices Enabled N / A Show detected USB devices
USB 1.1 Controller Disabled
2 Ports
4 Ports
6 Ports
Enable or disable the USB 1.1 controllers (UHCI)
USB 2.0 Controller Disabled
2 Ports
4 Ports
6 Ports
Enable or disable the USB 2.0 controllers (EHCI)
USB Client Controller Disabled
Enabled
Enable or disable the USB client controller
USB 2.0 Controller Mode FullSpeed
HiSpeed
Set the USB 2.0 controllers to HiSpeed (480 Mbps) or Full-
Speed (12 Mbps) for legacy mode
BIOS USB 2.0 Hand-Off Disabled
Enabled
This patch must be allied for operating systems before WIN
XP which have problems gaining control over USB 2.0 ports.
If enabled this provides a simple semaphore based mecha-
nism for exchanging USB 2.0 (EHCI) ownership
8USB Mass Storage
Device Configuration
Submenu Display the status of USB mass storage devices
18.5.2.5.1 USB Mass Storage Device Configuration Submenu
Feature Option Description
USB Mass Storage Reset
Delay
10 Sec.
20 Sec.
30 Sec.
40 Sec.
Set the initialization delay time
Device N / A Show the device identifier
Emulation Type Auto
Floppy
Forced FDD
Hard Disk
CDROM
Define the emulation type. Forced FDD can be used to force a
HDD formatted drive to boot as FDD
