KTD-S0002-I Page 58 Appendix B: Connector Layout
p ITX-SP User's Guide
B.3 Mating Connectors
The table notes mating connectors.
Identifier Mating Connector Comment
J1801 1.25 mm 7 pin
(MOLEX 51021-0700 or comp.)
for backlight cables
J2900 1.25 mm 6 pin
(MOLEX 51021-0600 or comp.)
for audio support (Line in, Line out
and Microphone)
J2901
1.25 mm 2 pin
(MOLEX 51021-0200 or comp.)
for S/PDIF support
J3301 - J3304
1.25 mm 4 pin
(MOLEX 51021-0400 or comp.)
for USB adapter
