KTD-S0002-I Page 41 Setup Guide
p ITX-SP User's Guide
18.5.2 Onboard Device Configuration Submenu
Feature Option Description
8Chipset Configuration Submenu Set chipset options (e.g. audio)
8IDE Configuration Submenu Configure the IDE devices (P-ATA, S-ATA)
8SDIO Configuration
Submenu Configure the SDIO ports
8LAN Configuration Submenu Configure the PCI Express ® LAN controller
8USB Configuration Submenu Configure the USB support
8GPIO Configuration Submenu Configure the GPIO port
18.5.2.1 Chipset Configuration Submenu
Feature Option Description
Audio Controller Disabled
Enabled
Enable or disable the HD audio controller
Serial IRQ Mode Continuous
Quiet
Define the serial IRQ mode (Quiet = the chipset transfers
only if an IRQ is triggered)
Linux Reboot Fix Disabled
Enabled
Fix the reboot issue on Linux operating systems. Might cause
side effects
18.5.2.2 IDE Configuration Submenu
Feature Option Description
Serial-ATA Controller Disabled
Enabled
Enable or disable the S-ATA controller
Serial-ATA Type Native IDE
RAID/AHCI Both modes needs the Option ROM
Serial-ATA Option ROM Disabled
Enabled
If disabled legacy operating systems not available (only
Windows
® and Linux working). Save boot time
Parallel-ATA Controller Disabled
Enabled
Enable or disable the P-ATA controller
Parallel-ATA BusMaster Disabled
Enabled
If enabled improves the performance of the IDE interface for
some operating systems (e.g. DOS)
8Parallel-ATA Master Submenu Display the status of autodetection (Master drive)
8Parallel-ATA Slave Submenu Display the status of autodetection (Slave drive)
Hard Disk Write Protect Disabled
Enabled
Allows the write protection of harddisk devices. Only valid if
the device is accessed through the BIOS
ATA(PI) Detect Time Out 0 Sec. ... 35 Sec. Select the time out value for the detection of ATA(PI) devices
ATA(PI) 80Pin Cable
Detection
Host&Device
Host
Device
Select the mechanism for detecting 80 pin cable
