Kontron pITX-SP - Manual (Page 48)

KTD-S0002-I Page 43 Setup Guide
p ITX-SP User's Guide
18.5.2.3 SDIO Configuration Submenu
Feature Option Description
Module Version N / A Show SDIO module version
SDIO Devices Enabled N / A Show detected SDIO devices
SDIO Controller Disabled
Enabled
Enable or disable both SDIO controller
Data Access Mode Auto
DMA
PIO
Auto selects the optimum access mode (sets PIO mode if
DMA not possible)
microSD Write Protect Disabled
Enabled
If enabled the device in the microSD Card socket is write
protected
8SDIO Mass Storage
Device Configuration
Submenu Display the status of SDIO mass storage devices
18.5.2.3.1 SDIO Mass Storage Device Configuration Submenu
Feature Option Description
Device N / A Show the device identifier
Emulation Type Auto
Floppy
Forced FDD
Hard Disk
Define the emulation type. Forced FDD can be used to force a
HDD formatted drive to boot as FDD
18.5.2.4 LAN Configuration Submenu
Feature Option Description
MAC Address N / A Show the programmed MAC address
LAN Controller Disabled
Enabled
Enable or disable the onboard PCIe LAN controller
PXE LAN Boot Disabled
Enabled
Enable or disable the option ROM to allow LAN boot functio-
nality
