Getting Started

ITX-SP User's Guide

Getting Started

Getting started with the pITX-SP is very easy. Take the following steps:

Plug a suitable DDR2-SDRAM memory module into the RAM socket.

Connect a DVI monitor to the DVI connector.

Plug a keyboard and/or mouse to the USB connector(s).

Plug a data cable to the harddisk interface. Attach the harddisk to the connector at the oppo-
site end of the cable. If necessary connect the power supply to the harddisk’s power connec-
tor.

Make sure all your connections have been made correctly. Connect the power supply to the
pITX-SP power supply connector.

Turn on the board by shortening the power button pins on power front panel header (J1804)
or use the autostart jumper (J1200).

Enter the BIOS by pressing the Del key during boot-up. Make all changes in the BIOS Setup.
See chapter

BIOS Setup

for further details.
