KTD-S0002-I Page 38 Setup Guide
p ITX-SP User's Guide
Legend Bar
Use the keys listed in the legend bar on the bottom to make your selections or exit the current menu. The
table below describes the legend keys and their alternates.
Key Function
or General help window
Exit menu
← or → Arrow key Select a menu
↑ or ↓ Arrow key Select fields in current menu
or Move cursor to top or bottom of current window
or Move cursor to next or previous page
Load the default configuration values for this menu
Save and exit
Execute command or select submenu
Refresh screen
Selecting an Item
Use the ↑ or ↓ key to move the cursor to the field you want. Then use the + and – keys to select a value for
that field.
Displaying Submenus
Use the ← or → key to move the cursor to the submenu you want. Then press . A pointer ()
marks all submenus.
Item Specific Help Window
The help window on the right side of each menu displays the help text for the selected item. It updates as
you move the cursor to each field.
General Help Window
Pressing or on a menu brings up the general help window that describes the legend keys and
their alternates. Press to exit the general help window.
