KTD-S0002-I Page 13 Graphics Interface
p ITX-SP User's Guide
6.2 Flat Panel Connector (JILI30)
The LVDS interface for the flat panel is available through the J1802 connector (30 pins) on the bottom side
of the board. This connector represents the JILI interface. The implementation of this subsystem complies
with the JILI specification of KONTRON Technology A/S. A variety of cables for different display types are
available from KONTRON. Please refer to the actual
Display Cable Guide on the same product web site.
Header Pin Signal Name Function
1 FTX0- First channel data output 0 (negative)
2 FTX0+ First channel data output 0 (positive)
3 FTX1- First channel data output 1 (negative)
4 FTX1+ First channel data output 1 (positive)
5 FTX2- First channel data output 2 (negative)
6 FTX2+ First channel data output 2 (positive)
7 GND Ground
8 FTXC- First channel clock output (negative)
9 FTXC+ First channel clock output (positive)
10 FTX3- First channel data output 3 (negative)
11 FTX3+ First channel data output 3 (positive)
12 N.C. Not connected
13 N.C. Not connected
14 GND Ground
15 N.C. Not connected
16 N.C. Not connected
17 GND Ground
18 N.C. Not connected
19 N.C. Not connected
20 N.C. Not connected
21 N.C. Not connected
22 N.C. Not connected
23 N.C. Not connected
24 GND Ground
25 SDA I2C data line
26 DATAENA Panel power output
27 SCL I2C clock line
1
30
28 - 30 VCC 1) Power +3.3V or +5V
