KTD-S0002-I Page 24 Audio Interface
p ITX-SP User's Guide
11 Audio Interface
The chipset supports a HD audio codec with 24 bit resolution and 192 kHz sample rate. The interface inclu-
des LINE OUT, LINE IN, MICROPHONE IN and a digital S/PDIF output. The HD audio controller is a bus
mastering PCI device which is physically connected to one or more codecs via the HD audio link. It contains
one or more DMA engines. For signal levels see the High Definition audio specification (Intel
® ).
11.1 Hardware Features
Parameter Values Units
Output resolution (LINE OUT, S/PDIF) 16/20/24 bit
Output sample rate (LINE OUT, S/PDIF) 44.1/48/96/192 kHz
Output signal-to-noise ratio (LINE OUT) 97 dB
Output current (S/PDIF) 12 @ 75Ω mA
Input resolution (LINE IN) 16/20 bit
Input sample rate (LINE IN) 44.1/48/96 kHz
Input signal-to-noise ratio (LINE IN) 90 dB
11.2 Analog Connector
The analog audio interface is available through the connector J2900 (6 pins). A prototype adapter cable
(open ended) is deliverable from KONTRON (KAB-SOUND-CMP-2, part number 96063-0000-00-1).
Header Pin Signal Name Function
1 LINE_OUT_R Line output right
2 GND Ground
3 LINE_OUT_L Line output left
4 LINE_IN_R Line input right
5 MIC_IN Microphone input
6 LINE_IN_L Line input left
11.3 Digital Connector (S/PDIF)
The digital audio output is available through the connector J2901 (2 pins).
Header Pin Signal Name Function
1 GND Ground
1 2 SPDIF_OUT S/PDIF output
