KTD-S0002-I Page 45 Setup Guide
p ITX-SP User's Guide
18.5.2.6 GPIO Configuration Submenu
Feature Option Description
GPIO Pin 0
GPIO Pin 1
GPIO Pin 2
GPIO Pin 3 Input
IRQ Input
Output
Tri-State
Define the GPIO type (Tri-State also output)
GPIO Pin 4
GPIO Pin 5
GPIO Pin 6
GPIO Pin 7 Input
IRQ Input
Output
Tri-State
Define the GPIO type (Tri-State also output)
Default Output State Low
High
Define the default level of all outputs (including Tri-
State)
18.5.3 Display Configuration Submenu
Feature Option Description
VGA BIOS Revision N / A Show the VGA BIOS revision
JDA Revision N / A Show the JDA revision (JILI Data Area)
Protocols N / A Show supported protocols (e.g. JILI3, EDID, DisplayID)
Frame Buffer Size 1 MB
4 MB
8 MB
Select the amount of system memory used by the onchip
graphic controller
Boot Display Device DVI Only
LCD Only
Control the boot display
Flat Panel Type VGA 640x480 1x18
SVGA 800x600 1x18
XGA 1024x768 1x18
XGA 1024x768 1x24
WXGA 1280x768 1x24
WVGA 800x480 1x18
WXGA 1366x768 1x24
WXGA 1280x800 1x18
Auto
Select a predefined flat panel resolution. If Auto the
board is searching for a JILI3 (KONTRON), EDID (VESA)
or a DisplayID (VESA) record
Flat Panel Scaling Centered
Stretched
Stretched display the screen content at the maximum
size otherwise the content is centered
Backlight Brightness 0 %, 10 %, 20%
30 %, 40 %, 50 %
60 %, 70 %, 80 %
90 %, 100 %
Set the backlight value (0% = 0V, 100% = +5V)
