VMOD-2/VMOD-2D
12/15/97
Configuration
Page 3 - 11 Man. ID 03139, Rev. Index 0200
x = B14 and B15 can be left at any setting when using 8 KByte address block widths. Default Setting bold/italic
Open 256 Byte AB #31 Open Open Open Open Set $FE F4 00 $FE F4 FF
Open 256 Byte AB #32 Open Open Open Open Open $FE FC 00 $FE FC FF
Set 8 KByte AB#01..04 Set Set Set x x $FE 00 00 $FE 1F FF
Set 8 KByte AB#05..08 Set Set Open x x $FE 20 00 $FE 3F FF
Set 8 KByte AB#09..12 Set Open Set x x $FE 40 00 $FE 5F FF
Set 8 KByte AB#13..16 Set Open Open x x $FE 60 00 $FE 7F FF
Set 8 KByte AB#17..20 Open Set Set x x $FE 80 00 $FE 9F FF
Set 8 KByte AB#21..24 Open Set Open x x $FE A0 00 $FE BF FF
Set 8 KByte AB#25..28 Open Open Set x x $FE C0 00 $FE DF FF
Set 8 KByte AB#29..32 Open Open Open x x $FE E0 00 $FE FF FF
Table 3-9: Address Width (B16) and Range (B2 and B12...15) Selections
B16 AB Size
Address
Block #s
B2 A15 B12 A14 B13 A13 B14 A12 B15 A11
Address Range
From ... To
