VMOD-2/VMOD-2D
12/15/97
Product Overview
Page 1 - 14 Man. ID 03139, Rev. Index 0200
PB-CNT 2x32-bit or
4x16-bit
Counter, @
500 kHz
max. input
speeds. 2/4 opto-iso-
lated
counter
inputs, 24V/
5mA (5V/
10mA)
[12V] {15V} - 523-12
(523-12/1)
[523-12/2]
{523-12/3}
PB-SIO4 Quad Serial
I/O 68681
RS232 +
RTS and
CTS 4 x RS232, non-opto (opto-
isolated) 523-15
(523-15/1)
PB-STP Single Axis
multi-mode
Stepper
Motor Con-
troller. 6 control
lines @
24V (5V )
[12V ] /
11mA opto-
isolated 10 lines / 1
Axis 24V
(5V) [12V]
8mA opto-
isolated 523-22
(523-22/1)
[523-22/2]
PB-REL Eight SPDT
Relays - 8 x galv.-
isolated 523-26
PB-DAC 4 ch 12-bit D
to A Con-
verter
(10µ s ) - 4ch. 0-
10V± 10V
(0-
8.192V± 8.1
92V) 523-11
(523-11/1)
PB-DAC2 4 ch 12-bit D
to A Con-
verter
(10µ s ) - 4ch. 4-20
mA (0-20
mA) 523-17
(523-17/1)
PB-ADC 4 ch 12-bit D
to A Con-
verter
(10µ s ) 8 ch. 0-
10V± 10V - 523-28
PB-ADC-2 8 ch 10-bit A
to D Con-
verter
(16µ s) 8 ch. 0-20
mA 523-28/1
Table 1-4: Piggyback Overview
PB-Name
Brief
Description
Ch. @ V In
Ch. @ V
Out
Order #
