istic is different in each order number type. The body text (normal) applies to all versions of
that piggyback type.
Table 1-4: Piggyback Overview
PB-Name
Brief
Description
Ch. @ V In
Ch. @ V
Out
Order #
PB-DIO 20 Ch. Digi-
tal I/O with
68230 and
24-bit timer 10 ch. at 5V
/10mA opto,
Cmn Vcc 10 ch. at 5V/
10mA opto,
Cmn Ground 523-13/1
PB-DIO2 20 Ch. Digi-
tal I/O with
68230 and
24-bit timer 10 ch. 24V /
5mA opto,
Cmn Vcc 10 ch. 24V/
100mA opto,
CG (CV) 523-16
(523-16/1)
PB-DIO3 20 Ch. Digi-
tal I/O with
68230 and
24-bit timer 10 ch. 24V /
5mA opto,
Cmn Gnd 10 ch. 24V/
100mA opto,
CG (CV) 523-23
(523-23/1)
PB-DIO4 16 Ch. High
Voltage Dig-
ital I/O 8 ch.12 to
80V / 5mA
opto CG in
pairs 8 ch 5 to
80V/500mA
opto OC CE
in pairs 523-27
PB-DIN 20 Ch. Digi-
tal Input
68230 and
24-bit timer 20 ch. 24V
(5V) 10mA
opto CV - 523-14
(523-14/1)
PB-DIN2 12 Ch. Hi-V
Digital Input 12 individ-
ual ch.s 12
to 60V 5mA - 523-24
PB-DOUT 12 Ch. High
Voltage Dig-
ital Output - 12 individ-
ual ch.s 5 to
80V/500mA 523-25
PB-CIO 20 Ch.
"Change of
State"
Z8536
Inputs 20 (18) CV
ch.s opto
24V/7.5mA (2 indepen-
dant ch.
24V/5mA
opto) 523-19
(523-19/1)
