VMOD-2/VMOD-2D
12/15/97
Product Overview
Page 1 - 4 Man. ID 03139, Rev. Index 0200
Figure 1-1: VMOD-2 Hazard Example (PB-REL)
Caution!
When using Piggybacks with external interfaces or supplies carrying Volt-
ages higher than 50V dc ensure that the solder pins on the rear side of
the PB-xxx and the VMOD to which it fits, are not accessible (cannot be
accidently touched) during use. These pins can be under power all the
time the external interfaces are connected, when powered,
even when VMOD-2/VMEbus is not powered!
26-pin
ST 2
Connector
This end towards
front of VMOD
8 x SPDT
Relays
GAL &
Interface
Logic ICs
Caution!
enclosed area
carries your
externally
connected
voltages and
may present
shock hazard
