VMOD-2/VMOD-2D
12/15/97
Product Overview
Page 1 - 9 Man. ID 03139, Rev. Index 0200
Hardware Features:
* Full electro/mechanical compatibility with the existing VMOD piggybacks and with the
very latest VMOD-2 enhanced piggybacks.
* All necessary VMEbus lines are made available to each of the piggybacks.
* 2.5 kV Galvanic VME to external isolation (not on index 00 boards), and PB to PB inter-
faces supporting opto-isolated piggybacks and the opto-isolated external "local" reset
input circuits.
* Extended temperature versions of both the VMOD-2 and many of the currently available
piggybacks, allowing combinations suitable for harsh industrial environments to be con-
figured.
