4 W D D Y N O I N S T A L L A T I O N
Deck Installation
Version 8 Above Ground Model 424x/424xLC 2 Automotive Dynamometer Installation Guide
3-45
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DECK INSTALLATION
Use the following instructions to install the deck.
Note: Refer to Appendix C for instructions on upgrading an existing deck.
You will need the following parts:
• 1011 Ground Hook/D-Ring (6)
• 10112 D-Ring Bracket, Surface Mount (6)
• 21214300 Center Panel
• 21214301 Outer Panel (2)
• 21610807 Support Angle (2)
• 21614102 Deck Brace Mount (2)
• 21619103 Tube
• 21714200 Deck Brace (4)
• 35521420 Cap Plug (2)
• 36561045 Screw, 1/4-20 x 5/8", Pan-Head, Torx (12)
• 36488100 Nut, 3/8-16, Nylock (22)
• 36582471 Bolt, 3/8-16 x 1.5", Flange-Hex (30)
• 36584871 Bolt, 3/8-16 x 3", Flange-Hex (4)
• 36923100 Washer, 3/8", Hardened, Flat, Steel, (22)
• DM150-020-005 Nut, Crush, 1/4-20 (12)
