C H A P T E R 1
Introduction
1-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INTRODUCTION
Before installing your dyno, please take a moment to read this guide for installation
instructions, dyno features, and other important information. This guide is designed
to be a reference tool in your everyday work and includes the following chapters and
information:
S PECIFICATIONS AND O PERATING R EQUIREMENTS
This chapter describes the specifications and requirements for the dyno.
S TATIONARY D YNO I NSTALLATION
This chapter describes the procedures for installing the stationary dyno.
4WD D YNO I NSTALLATION
This chapter describes the procedures for installing the 4WD dyno.
E DDY C URRENT B RAKE I NSTALLATION
This chapter describes the procedures for installing the eddy current brake, torque
module, and load cell. This chapter also includes the procedures for load cell
calibration.
S IDE D ECK A SSEMBLY I NSTALLATION
This chapter describes the procedures for installing the side deck assembly.
B ASIC D YNO O PERATION
This chapter describes basic dyno operating procedures and maintenance.
R ED H EAD I NSTALLATION
This appendix describes the procedures for installing the Red Head anchors.
P OWER R EQUIREMENTS
This appendix describes the power requirements and installation instructions for the
eddy current brake.
S TATIONARY D YNO U PGRADE
This appendix describes the procedures for upgrading an existing stationary dyno to
be used with the 4WD dyno.
B RIDGE E XTENSION A SSEMBLY
This appendix describes the procedures for installing the bridge extension assembly.
I NTERFACE R OLLER A SSEMBLY I NSTALLATION
This appendix describes the procedures for installing the interface roller assembly.
T ORQUE V ALUES
This appendix describes the standard and metric torque values.
