Above Ground Model 424x/424xLC 2 Automotive Dynamometer Installation Guide
C H A P T E R 5
Side Deck Installation
5-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SIDE DECK INSTALLATION
This section describes how to install the side deck assembly. The side deck assembly is
an optional accessory; if you did not order this accessory skip this chapter.
You will need the following parts:
• 36562470 Bolt, 1/4-20 x 1.5", Hex (8)
• 36584870 Bolt, 3/8-16 x 3", Hex (8)
• 36912100 Washer, 1/4", Splitlock, Steel (8)
• 36923100 Washer, 3/8", Hardened, Flat, Steel, (16)
• 36932100 Washer, 3/8", Splitlock, Steel (8)
• 61319501 Step Side, Right
• 61319502 Step Side, Left
• 61319503 Step Frame (2)
• 61319504 Leg Assembly (2)
• 61319505 Platform Assembly
• DM150-009-003 Washer, 1/4", Flat (16)
• DM150-009-005 Nut, 1/4" (8)
• DM150-011-004 Nut, 3/8-16, Hex (8)
