Dynojet 424x: Installation Guide User Manual
Page 56
Above Ground Model 424x/424xLC
2
Automotive Dynamometer Installation Guide
C H A P T E R 3
Cable Routing
3-18
Figure 3-10: Wiring the Breakout Board—With One Eddy Current Brake
jumpers
J1 and J2
four wheel drive
with one eddy
current brake
jumper settings
pickup card
stationary
pickup card
4WD
brake signal
theta signal
temperature
sensor
