5 - side deck assembly installation – Dynojet 424x: Installation Guide User Manual
Page 119
Above Ground Model 424x/424xLC
2
Automotive Dynamometer Installation Guide
5-1
C
H A P T E R
5
S
IDE
D
ECK
A
SSEMBLY
I
NSTALLATION
This chapter will walk you through installing the side deck assembly. To ensure safety
and accuracy in the procedures, perform the procedures as they are described.
This chapter is divided into the following categories:
• Side Deck Installation, page 5-2
