B A S I C D Y N O O P E R A T I O N
Loading the Vehicle
Version 8 Above Ground Model 424x/424xLC 2 Automotive Dynamometer Installation Guide
6-3
9 Attach the tie-down straps.
Rear Wheel Drive
• Attach two tie-down straps from secure anchor points to the rear of the
vehicle. Attach additional tie-down straps from the rear of the vehicle as shown
in Figure 6-2.
• Attach two tie-down straps from secure anchor points to the front of the
vehicle.
Front Wheel Drive
• Attach two tie-down straps from secure anchor points to the rear of the
vehicle.
• Attach two tie-down straps from secure anchor points to the front of the
vehicle. Attach additional tie-down straps across the front of the vehicle to
form a crisscross.
With front wheel drive vehicles, always use longitudinal and cross straps at the
front of the vehicle.
Four Wheel (All-Wheel) Drive
• Attach two tie-down straps from secure anchor points to the rear of the
vehicle. Attach additional tie-down straps across the rear of the vehicle to form
a crisscross.
• Attach two tie-down straps from secure anchor points to the front of the
vehicle. Attach additional tie-down straps across the front of the vehicle to
form a crisscross.
With four wheel drive vehicles, always use longitudinal and cross straps at the
front of the vehicle.
Figure 6-2: Attach the Tie-down Straps
rear wheel drive front wheel drive four wheel drive
