Contents 3
Contents
1 About Your Solution
. . . . . . . . . . . . . . . . . .
9
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Dell PowerVault NX3500 Front-Panel Features
and Indicators
. . . . . . . . . . . . . . . . . . . . . . 10
LCD Panel Features . . . . . . . . . . . . . . . . . . . 12
Home Screen . . . . . . . . . . . . . . . . . . . . 14
Setup Menu . . . . . . . . . . . . . . . . . . . . . 14
View Menu . . . . . . . . . . . . . . . . . . . . . 15
Hard-Drive Status Indicators . . . . . . . . . . . . . . 16
PowerVault NX3500 Back-Panel Features
and Indicators
. . . . . . . . . . . . . . . . . . . . . . 17
NIC Indicator Codes . . . . . . . . . . . . . . . . . . . 18
Power Indicator Codes . . . . . . . . . . . . . . . . . 19
Dell Backup Power Supply Front-Panel Features
. . .
20
Backup Power Supply Indicators . . . . . . . . . . . . 21
Backup Power Supply Back-Panel Features . . . . . . 22
LCD Status Messages . . . . . . . . . . . . . . . . . . 22
Solving Problems Described by LCD
Status Messages . . . . . . . . . . . . . . . . . . 34
Removing LCD Status Messages
. . . . . . . . . .
35
System Messages . . . . . . . . . . . . . . . . . . . . 35
