System Board Information
6 D1 – D4 memory modules D1 – D4
7 CPU4 Processor 4 socket
8 C1 – C4 memory modules C1 – C4
9 PSWD_EN,
NVRAM_CLR system configuration jumpers
NOTE:
Access requires removal of system board. See
"Removing the System Board" on page 150.
10 connector for the 3.0-V coin battery
NOTE:
Access requires removal of system board. See
"Removing the System Board" on page 150.
11 J_STORAGE Storage controller card connector
12 Hard-drive backplane connector
13 Hardware key socket for integrated NIC TOE/iSCSI
feature
14 CPU3 Processor 3 socket
15 CPU1 Processor 1 socket
16 A1 – A8 memory modules A1 – A8
17 video controller card connector
18 MEZZ1_FAB_C Mezzanine card connector 1 Fabric C
19 MEZZ2_FAB_B Mezzanine card connector 2 Fabric B
20 MEZZ3_FAB_C Mezzanine card connector 3 Fabric C
NOTE:
For the full name of an abbreviation or acronym used in this table, see the
"Glossary" on page 219.
Table 7-5. PowerEdge M905 System Board Connectors (continued)
Connector Description
