Installing Enclosure Components
169
Figure 4-7. Removing and Installing the Bezel
Installing the Enclosure Bezel
1 Attach the bezel to the enclosure using the eight screws. See Figure 4-7.
2 Connect the ribbon cable to the LCD module, and reinstall the cover
plate.
Enclosure Midplane (Service Only)
Removing the Front Module Cage Assembly and Midplane
CAUTION:
Only trained service technicians are authorized to remove the system
cover and access any of the components inside the system. Before you begin this
procedure, review the safety instructions that came with the system.
1 bezel 2 enclosure
3 screws (8)
1
2
3
