an error condition, remove the optional bezel to see further information provided by the status LCD.
The LCD can display two lines of alphanumeric characters. The display codes are presented in two color combinations:
l White characters on a blue background — Information only; no action is required.
l Amber characters on a black background — The system needs attention.
Table 2 -7 lists the LCD status messages that can occur and the probable cause for each message. The LCD messages refer to events recorded in the system
event log (SEL). For information on the SEL and configuring system management settings, see the systems management software documentation.
Table 2-7. LCD Status Messages
CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the components inside the system. See
your Product Information Guide for complete information about safety precautions, working inside the computer, and protecting against
electrostatic discharge.
Line 1
Message Line 2
Message Causes Corrective Actions
SYSTEM
ID
SYSTEM NAME SYSTEM ID is a unique name, five characters or
less, defined by the user.
SYSTEM NAME is a unique name, 16 characters or
less, defined by the user.
The system ID and name display under the
following conditions:
l The system is powered on.
l The power is off and active POST errors
are displayed.
This message is for information only.
You can change the system ID and name in the System Setup program. See
your system's User's Guide for instructions.
E0000 OVRFLW CHECK
LOG
LCD overflow message.
A maximum of three error messages can display
sequentially on the LCD. The fourth message
displays as the standard overflow message.
Check the SEL for details on the events.
E0119 TEMP AMBIENT Ambient system temperature is out of acceptable
range. See " Troubleshooting System Cooling Problems " in "Troubleshooting Your
System."
E0119 TEMP BP Backplane board is out of acceptable temperature
range.
E0119 TEMP CPU n Specified microprocessor is out of acceptable
temperature range. See " Troubleshooting System Cooling Problems " in "Troubleshooting Your
System." If the problem persists, ensure that the microprocessor heat sinks
are properly installed (see "
Replacing a Processor " in "Installing System
Components").
E0119 TEMP SYSTEM System board is out of acceptable temperature
range. See " Troubleshooting System Cooling Problems " in "Troubleshooting Your
System."
E0212 VOLT 3.3 System power supply is out of acceptable voltage
range; faulty or improperly installed power
supply. See " Troubleshooting Redundant Power Supplies " in "Troubleshooting Your
System."
E0212 VOLT 5
E0212 VOLT 12
E0212 VOLT BATT Faulty battery; faulty system board. See " Troubleshooting the System Battery " in "Troubleshooting Your System."
E0212 VOLT BP 12 Backplane board is out of acceptable voltage
range. See " Troubleshooting Redundant Power Supplies " in "Troubleshooting Your
System."
E0212 VOLT BP 3.3
E0212 VOLT BP 5
E0212 VOLT CPU VRM Microprocessor VRM voltage is out of acceptable
range; faulty or improperly installed
microprocessor VRM; faulty system board. This message is not applicable to this system.
E0212 VOLT NIC 1.8V Integrated NIC voltage is out of acceptable
range; faulty or improperly installed power
supply; faulty system board. See " Troubleshooting Redundant Power Supplies " in "Troubleshooting Your
System."
E0212 VOLT NIC 2.5V
E0212 VOLT PLANAR
REG
System board is out of acceptable voltage range;
faulty or improperly installed system board.
E0276 CPU VRM n Specified microprocessor VRM is faulty,
unsupported, improperly installed, or missing. These messages are not applicable to this system.
E0276 MISMATCH VRM
n
E0280 MISSING VRM n
E0319 PCI OVER
CURRENT
Faulty or improperly installed expansion card. See " Troubleshooting Expansion Cards " in "Troubleshooting Your System."
E0412 RPM FAN n Specified cooling fan is faulty, improperly installed,
or missing. See " Troubleshooting System Cooling Problems " in "Troubleshooting Your
System."
E0780 MISSING CPU 1 Microprocessor is not installed in socket 1. Install a microprocessor in socket 1 (see " Replacing a Processor " in "Installing
System Components"). To identify microprocessor socket 1, see Figure A -3 .
E07F0 CPU IERR Faulty or improperly installed microprocessor. See " Troubleshooting the Microprocessors " in "Troubleshooting Your System."
