8.

Close the system. See "

Closing the System

."




9.

Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.



10.

If the problem is not resolved, see "

Getting Help

."



Troubleshooting a NIC



Problem

l



NIC cannot communicate with network.



Action



1.

Run the appropriate online diagnostic test. See "

Using Server Administrator Diagnostics

" in "Running System Diagnostics."




2.

Enter the System Setup program and confirm that the NICs are enabled. See "Using the System Setup Program" in your User's Guide.



3.

Check the appropriate indicator on the NIC connector. See "

NIC Indicator Codes

" in "Indicators, Messages, and Codes."

l



If the link indicator does not light, check all cable connections.

l



If the activity indicator does not light, the network driver files might be damaged or missing.

Remove and reinstall the drivers if applicable. See the NIC's documentation.

l



Use another connector on the switch or hub.

If you are using a NIC card instead of an integrated NIC, see the documentation for the NIC card.



4.

Ensure that the appropriate drivers are installed and the protocols are bound. See the NIC's documentation.



5.

Ensure that the NICs, hubs, and switches on the network are all set to the same data transmission speed. See the network equipment documentation.



6.

Ensure that all network cables are of the proper type and do not exceed the maximum length. See "Network Cable Requirements" in your User's Guide.

 Responding to a Systems Management Software Alert Message

Systems management software monitors critical system voltages and temperatures, fans, and hard drives in the system. Alert messages appear in the Alert
Log
window. For information about the Alert Log window, see the systems management software documentation.



Inside the System

In

Figure 5

-1

, the bezel and system cover are removed to provide an interior view of the system.



Figure 5-1. Inside the System
