8.

Close the expansion-card retainer.



9.

Reinstall the expansion-card cage. See "

Installing the Expansion-Card Cage

."




10.

Close the system. See "

Closing the System

" in "Troubleshooting Your System."



Removing a Hot-Plug Expansion Card





1.

Open the system. See "

Opening the System

" in "Troubleshooting Your System."




2.

To power down the expansion slot, press the indicator/switch at the end of the expansion slot. See

Figure 6

-14

.




3.

Wait until the green and amber indicators for the slot are both off. See

Figure 6

-14

and

Table 6

-1

.




4.

Disconnect any internal or external cable(s) that are connected to the expansion card.



5.

Open the expansion-card retainer adjacent to the PCI slot.



6.

Grasp the expansion card and carefully remove it from the riser-card connector.



7.

If you are permanently removing the card, replace the metal filler bracket over the empty card-slot opening.



8.

Close the expansion-card retainer.



9.

Close the system. See "

Closing the System

" in "Troubleshooting Your System."



System Memory

You can upgrade your system memory to a maximum of 16 GB by installing combinations of 256-MB, 512-MB, 1-GB, 2-GB, or 4-GB (when available) 2-way
registered ECC PC2-3200 (DDR II 400) memory. The memory sockets are located on the system board adjacent to the power supply bays. See

Figure 6

-1

.

The system memory is located on the system board adjacent to the power supply bays. See

Figure 6

-1

. The memory module sockets are arranged in three

banks on two channels (A and B). The memory module banks are identified as follows:

l



Bank 1: DIMM1_A and DIMM1_B

l



Bank 2: DIMM2_A and DIMM2_B

l



Bank 3: DIMM3_A and DIMM3_B



General Memory Module Installation Guidelines

l



If only one memory module is installed, it must be installed in socket DIMM1_A or DIMM1_B.

l



If two or more memory modules are installed, they must be installed in pairs of matched memory size, speed, and technology.

l



The system supports both single-ranked and dual-ranked memory modules.

l



If you install both single-ranked and dual-ranked memory modules, the dual-ranked memory modules must be installed in bank 1.

l



Dual-ranked memory modules are not supported in bank 3.

l



If dual-ranked memory modules are installed in bank 2, you cannot install any memory modules in bank 3.

Memory modules marked with a 1R are single ranked and modules marked with a 2R are dual ranked. See

Figure 6

-15

.



Figure 6-15. Determining a Memory Module's Capacity and Rank

CAUTION:

See your Product Information Guide for complete information about safety precautions, working inside the computer, and protecting

against electrostatic discharge.

NOTE:

Filler brackets must be installed over empty expansion-card slots to maintain FCC certification of the system. The brackets also keep dust

and dirt out of the system and aid in proper cooling and airflow inside the system.

NOTE:

Two-way interleaving is not supported in the 256-MB single memory module configuration.

NOTICE:

If you remove your original memory modules from the system during a memory upgrade, keep them separate from any new memory modules

that you may have. Use only registered ECC PC2-3200 compliant (DDR II 400) memory modules.
