How to copy exchange data to a network folder – Dell PowerVault DP600 User Manual

Page 53

4. On the calendar, click any date in bold to obtain the recovery points available for that

date. The Recovery time menu lists the time for each available recovery point.

5. On the Recovery time menu, select the recovery point you want to use.

6. In the Actions pane, click Recover.

The Recovery Wizard launches. The wizard options will vary depending on the version of

Exchange.

7. On the Review recovery selection page, click Next.

8. Select Recover to another database on an Exchange Server, and then click Next.

9. On the Specify recovery options page, you can select Send an e-mail when this

recovery completes.

Select this option to specify an e-mail address or addresses to notify upon recovery

completion. If you select this option, you must enter the e-mail address to notify. Multiple

e-mail addresses must be separated by a comma.

10. On the Summary page, review the recovery settings, and then click Recover.

How to Copy Exchange Data to a Network Folder

When you copy a storage group to a network folder, Data Protection Manager (DPM) creates the

following directory structure at the destination that you specify:

DPM_Recovery_Point_timestamp\DPM_Recovered_At_timestamp\Server name\Exchange

application\Database name\Files

Example:

DPM_Recovery_Point_8-12-2007_0.1.54AM\DPM_Recovered_At_8-13-

2007_10.49.21AM\Server1.DPM.LAB\J-Volume\Files

The DPM protection agent and the Eseutil utility must be installed on the destination server. The

Eseutil utility can be installed as part of either a Microsoft Exchange Server installation or an

Exchange Server Administrator-only-mode installation.

How to copy Exchange data to a network folder

1. In DPM Administrator Console, click Recovery on the navigation bar.

2. Using the browse functionality, select the storage group or database to recover.
