Dell ™ Latitude™ XT2 XFR Service Manual
Page 48 of 94 Version A00-01
13. Install the WLAN/WWAN mini-cards. (See mini-card chapter for reference)
14. Install the memory module. (See memory chapter for reference)
15. Install the mini-card and memory door. (See memory cover chapter for reference)
16. Install the hard drive. (See hard drive chapter for reference)
17. Install the battery. (See battery chapter for reference)
4.10 Coin-Cell Battery
WARNING: Before working inside your XT2 XFR, read the safety information that
shipped with your XT2 XFR. For additional safety best practices information, see the
Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
4.10.1 Removing the Coin-Cell Battery
1. Follow the procedures in Before Working Inside Your XT2 XFR .
2. Follow the procedures in removing the palm rest before continuing.
3. Disconnect the coin-cell battery from the system board and remove from the XT2 XFR
