My Network Places, History, and Favorites provide remote connection functionality not supported by the
PowerVault 715N system and should be ignored.
Right Pane
The right pane identifies the various objects and their status, and displays any error conditions that might exist. The four
tabbed views in the system's right-pane console view include the following tabs:
The General tab displays parameters based on the objects you select in the console's tree view.
The parameters for Disks are as follows:
Name is the name of the object.
Status can vary, depending on the object. Common status conditions are Online, Healthy, and
Resynching.
Type identifies the object, such as Dynamic Disk.
Disk Group shows an entry for disks in a basic or dynamic group.
Capacity is the maximum size of the disk.
Unallocated Space is the amount of free hard drive space still available.
Graphical Layout is a graphical representation of how much of the disk is being used.
Progress shows the current progress (percentage of completion) for tasks.
Device is the type of disk: small computer system interface (SCSI), integrated drive electronics (IDE), and
so on.
Port identifies the controller card. A SCSI port has zero or more target IDs, and a target ID has one or more
logical unit numbers (LUNs).
LUN is the logical unit number.
Target is the SCSI ID that uniquely identifies the disk on the controller card.
Vendor identifies the vendor on hardware objects.
The parameters for Volumes are as follows:
Name is the name of the object.
Status can vary, depending on the object. Common status conditions are Online, Healthy, and
Resynching.
Layout identifies the object, such as Dynamic Mirrored Volume and Dynamic Striped Volume.
Disk Group shows an entry for disks in a basic or dynamic group.
Capacity is the maximum size of the disk.
Free Space is the amount of free hard drive space still available.
Progress shows the current progress (percentage of completion) for tasks.
File System shows the type of file system.
Graphical Layout is a graphical representation of how much of the disk is being used.
The Events tab displays event log messages associated with storage objects.
The Disk View tab displays a graphical layout of the disks on your system, including CD or other removable media.
The DM View tab is grayed-out on the Array Manager console.
