17. Repeat step 2 through step 16 to configure another array and logical drive.
The RAID controller supports up to 40 logical drives per controller.
18. When finished configuring logical drives, press to exit Easy Configuration.
A list of the currently configured logical drives appears.
19. Respond to the Save prompt.
After you respond to the Save prompt, the Configure menu appears.
20. Initialize the logical drives you have just configured.
See " Initializing Logical Drives "in this section for more information.
Using New Configuration
If you select New Configuration, the existing configuration information on the selected controller is destroyed when the new configuration is saved. In New
Configuration, you can modify the following logical drive parameters:
l RAID level
l Stripe size
l Write policy
l Read policy
l Cache policy
l Logical drive size
l Spanning of arrays
1. Select Configure—> New Configuration from the Management Menu.
Hot key information appears at the bottom of the screen.
2. Press the arrow keys to highlight specific physical drives.
3. Press the spacebar to associate the selected physical drive with the current array.
The selected drive changes from READY to ONLINE A[array number]-[drive number]. For example, ONLINE A2-3 means array 2 with hard drive 3.
4. Add physical drives to the current array as desired.
5. Press after you finish creating the current array.
The Select Configurable Array(s) window appears. It displays the array and array number, such as A-00.
6. Press the spacebar to select the array.
Span information displays in the array box. You can create multiple arrays, then select them to span them.
NOTE: The PERC 4 family supports spanning across RAID 1 and 5 arrays only.
NOTICE: Selecting New Configuration erases the existing configuration information on the selected controller. To use the spanning feature and keep
the existing configuration, use View/Add Configuration.
NOTE: Try to use drives of the same capacity in a specific array. If you use drives with different capacities in an array, all drives in the array are
treated as if they have the capacity of the smallest drive in the array.
