Page 87

4-41
4
Motherboard
Motherboard jumpers
The following table shows the factory default configuration for specific motherboard
jumpers. No other jumpers are used. Jumper configurations should not be changed.
Jumper
Jumper area
Description
(default configuration)
JP1
• Clear CMOS and password.
Normal operation = no jumper installed.
JP9
• PCI/PCI-X mode (PCI Bus 1/Slot 1)
Normal operation = PCI mode enabled; jumper installed.
This setting should not be changed.
JP10
• PCI/PCI-X mode (PCI Bus 2/Slot 2)
Normal operation = PCI mode enabled; jumper installed.
This setting should not be changed.
JP24
• Enable/Disable Intel 82551QM/8254OEM NIC chip
Normal operation = enabled; no jumper installed.
This setting should not be changed.
Open
2
1
2
1
Closed
2
1
Closed
2
1
Open
